Pego ECP200 Expert 2EV control panel

The Pego ECP 200 EXPERT 2EV control panel increases the range 200 EXPERT with a controller for cold rooms with single-phase compressor up to 2 HP and two evaporators, specially designed to provide safety, protection, control and ease-of-installation – all in one unit. It allows a complete control of all the components on a refrigeration system with new features added.

Applications
• Complete control of single-phase static or ventilated refrigeration systems up to 2 HP, with off-cycle or electrical defrosting and direct or pump-down compressor stop.
• Control of two evaporators with two temperature probes of end defrost.
• Control of evaporating unit (single or double evaporator) only with freon solenoid consensus o remote motor condenser consensus.

ECP200 Expert 2EV features:
• Direct control of compressor, defrosting heaters,  evaporator fans and room light with free-voltage  outputs.
• Built-in differential magnetothermic breaker for  protection and cut-off of refrigeration unit.
• Innovative, stylish design. Transparent cover for access to magnetothermic  breaker, all with  IP 65 protection rating.
• Auxiliary relay with parameter-configured activation (alarm, temperature set-point, direct control  via frontal pushbutton, thermostat-holder  demisting element, remote motor condenser unit  consensus, freon solenoid control consensus  where compressor pump-down operation is  applied).
• Dedicated enabling of condensing unit in single evaporator configuration.
• RS485 for connection to TeleNET industrial  supervision network.
• Guaranteed, certified safety and protection thanks to incorporated magnetothermic  differential circuit breaker, which cuts the general  power supply.
• Simple wiring.
• Easy installation and opening thanks to new  hinged cover.
• Simple, flexible programming gives extreme  versatility of use.
• Compressor can be run in pump-down stop mode.
• Installation times and costs reduced thanks to  incorporation of control and protection in a single  room-dedicated unit.
• Defrost with real time clock.
• Independent and separated functions for alarm  relay, condensing unit enable and TeleNET  monitoring system.
• HACCP function with memory of the last alarm  and number of alarm counter.
